Yanmar
6LY2A-STP
8LV Series
Yanmar Australia

Engine Specifications

Application

Powerboat Engine

Power Output (HP)

440

Power Output (kW)

324

Rated Speed

3300 RPM

Displacement

5.813L

Cylinders

6

Bore x Stroke

106mm x 110mm

Aspiration

Turbocharged & Intercooled

Dry Weight

535kg

Dimensions

1428mm x 692mm x 736mm

Controls

Mechanical

Certifications

RCD 1, IMO Tier 2, EMC, SOLAS

Series Information

For boats, the ability to slot an engine as low down as possible, or to mount twin engines low in the vee of the boat has been critical. The straight six has thus become the configuration of choice, as the crankshaft is still not as long as to require heavy strengthening, there is more capacity advantage over a four, and a six is far narrower than a vee-eight.

The mountability is excellent due to its flat top, and due to its narrow profile. Repowering a gasoline engine boat is now a pleasure, for this engine has more muscle and endurance to match virtually whatever was previously being used.

Features:

  • Great endurance and excellent fuel economy
  • More power and more speed
  • Excellent economy with superb performance
  • Proven Yanmar reliability



Race proven performance is inherited. Power-to-weight ratio is even more startling. Endurance and fuel economy are at a level that only a diesel could achieve.

It follows current user trends, the demand for more power and more speed. And because it is a diesel, smaller fuel tanks can be used saving hundreds of kgs of weigh, giving you an immediate speed increase.

The direct injection uses ultra-high-pressure fine mist injectors, making for excellent economy together with superb performance, with minimal smoke under hard use conditions. Fuel savings, precious energy savings, and an increase in safety accompany the change to a diesel.

All service points are conveniently placed high on the engine. Renowned Yanmar reliability and parts backup complete the package. An engine that will dramatically lift the performance of virtually ANY hull, and likely put you in the race winners seat, if you so desire.

Race bred, high performance straight six

The LY2A will dramatically lift the performance of virtually ANY hull, and likely put you in the race winners seat, if you so desire.

Standard Engine Package

  • Exhaust mixing elbow [L-type]
  • Alternator 12V – 80A



Optional Accessories

  • High-riser mixing elbow [instead of L-elbow]
  • Flexible mounts Barry
  • Flexible mounts Bridgestone
  • B/C/D-type instrument panel
  • Extension wire harness [4m, 6m, 10m]
  • Dual harness [for 2nd station]
  • Sensor for VDO instrument panels
  • SOLAS including Certificate [factory fit only]
  • Water separator

Compatible Products

Please contact your nearest dealer or Power Equipment Account Manager for a full list of available options, installation requirements and compatible products.

* All information shown is to be used as general information only. Images shown are for illustration purposes only and may not represent the final product. All dimensions, power outputs and technical details are approximate and may vary from time to time depending on a range of factors. Any data shown is subject to change without notice. Some items or accessories may not be available in all areas/regions. Please consult your Authorised Dealer or Power Equipment Account Manager for all technical information.
